  Electrosurgical Units Vessel sealing Systems





       Ligaseal :


 Quick Reference

 Technical Specification

  Specialized Vessel Sealing & Bipolar Generator.
  Graphical LCD Display.
  23 Procedures Selection Menu.
  Specific Modulated outputs for all procedures across all specialties for
    unmatched superior Performance.




  Display
:
 Graphical LCD Display.
  Dimension ( W x H x D )
:
 290 mm x 110 mm x 300 mm.
  Weight
:
 3 kg.
  Keyboard
:
 Feather Touch.
  Input Supply Voltage
:
 230 VAC + 15% @ 50/60 Hz (110 V optional).


 Sealer Modes



Mode
Max. Power Watt
Max. Short Circuit Current
Peak to Peak Voltage
Operating Frequency
Crest Factor
Soft
150
4.4 Amps
560 (280)
480 khz
1.5
Force
150
4.4 Amps
700 (350)
480 khz
1.5






 Bipolar Modes



Mode
Max. Power Watt
Max. Short Circuit Current
Peak to Peak Voltage
Operating Frequency
Crest Factor
Bi-Coag
120
2.2 Amps
560 (280)
480 khz
1.5
Bi-Cut
120
2.2 Amps
620 (310)
480 khz
1.5
